Module: as91906 Use complex programming techniques to develop a computer program
Requirements: programming or writing code for a graphical user interface (GUI), reading from, or writing to, files or other persistent storage, object-oriented programming using class(es) and objects defined by the student.
Go to topThere are no explanations provided here because no new concepts are introduced. It is simply all of the concepts previously introduced put together in a single application that contains both procedural and object oriented programming
The application allows the user to enter data into a database, modify individual records or delete them. The data can also be browsed sequentially.
"""
The short section below contains the imported libraries required for
for creating a GUI interface and processing a database
"""
import tkinter as tk
from tkinter import *
import sqlite3
"""
This class contains all of the data and methods required for simple
data processing for an employee
"""
class Employee:
__strIRD=""
__strName=""
__floatHours=0.0
__floatRate=0.0
__floatGross=0.0
__floatTax=0.0
__floatNet=0.0
__blnValidData=False
def __init__(self, ird, nme, hrs, rt):
if hrs >= 5 and hrs <= 60 and rt >=20 and rt <= 80:
self.__strIRD = ird
self.__strName = nme
self.__floatHours = hrs
self.__floatRate = rt
self.__blnValidData = True
self.__calculate()
def irdValue(self):
if self.__blnValidData:
return self.__strIRD
else:
return ""
def nameValue(self):
if self.__blnValidData:
return(self.__strName)
else:
return ""
def hoursValue(self):
if self.__blnValidData:
return self.__floatHours
else:
return -1
def rateValue(self):
if self.__blnValidData:
return self.__floatRate
else:
return -1
def grossValue(self):
if self.__blnValidData:
return self.__floatGross
else:
return -1
def taxValue(self):
if self.__blnValidData:
return self.__floatTax
return -1
def netValue(self):
if self.__blnValidData:
return self.__floatNet
else:
return -1
def __calculate(self):
self.__floatGross=self.__floatHours*self.__floatRate
self.__floatTax=self.__floatGross*0.25
self.__floatNet=self.__floatGross-self.__floatTax
def toString(self):
if self.__blnValidData:
strOutput = "IRD is " + self.__strIRD + "\n"
strOutput += "Name is " + self.__strName + "\n"
strOutput += "Hours worked is " + str(self.__floatHours) + "\n"
strOutput += "Hourly rate is " + str(self.__floatRate) + "\n"
strOutput += "Gross is " + str(self.__floatGross) + "\n"
strOutput += "Tax is " + str(self.__floatTax) + "\n"
strOutput += "Net is " + str(self.__floatNet) + "\n"
else:
strOutput = "Invalid data supplied to either hours or rate"
return strOutput
"""
This class contains the data members and the code required for opening
a database and reading, modifying and deleting its records
"""
class dBase():
__lstWorkers=[]
__position=int(-1)
__fileOpen=False
__fb=""
def __init__(self):
connection =sqlite3.connect("Workers.db")
cursor=connection.cursor()
cursor.execute("SELECT * from workers")
result=cursor.fetchall()
for rec in result:
emplIRD, emplname,hours,rate,gross,tax,net = rec
newWorker = Employee(emplIRD,emplname,hours,rate)
self.__lstWorkers.append(newWorker)
rec=None
self.__fileOpen=True
self.__fb = "Database contains " +str(len(self.__lstWorkers))+" records"
def payFirst(self):
if self.__fileOpen==True:
self.__position=0
return self.__lstWorkers[self.__position]
def payNext(self):
if self.__fileOpen==True:
self.__position+=1
if self.__position == len(self.__lstWorkers):
self.__position=0
return self.__lstWorkers[self.__position]
def payPrevious(self):
if self.__fileOpen==True:
self.__position-=1
if self.__position == -1:
self.__position=len(self.__lstWorkers)-1
return self.__lstWorkers[self.__position]
def payLast(self):
if self.__fileOpen==True:
self.__position = len(self.__lstWorkers)-1
return self.__lstWorkers[self.__position]
def newRecord(self, PIRD, PName, Hours,Rate):
if self.__fileOpen==True:
newWorker = Employee(PIRD, PName, Hours,Rate)
self.__lstWorkers.append(newWorker)
self.__saveList()
self.__fb = "Record for "+PIRD+", "+PName+" has been added"
def changeData(self,PIRD, PName, Hours,Rate):
if self.__fileOpen==True:
newWorker = Employee(PIRD, PName, Hours,Rate)
del self.__lstWorkers[self.__position]
self.__lstWorkers.insert(self.__position,newWorker)
strSQL="UPDATE workers SET emplname = '"+PName+"', hours ="+str(Hours)+", rate = "+str(Rate)+" where emplIRD = '"+PIRD+"'"
print(strSQL)
connection =sqlite3.connect("Workers.db")
cursor=connection.cursor()
cursor.execute(strSQL)
connection.commit()
cursor.close()
self.__fb = "Name for "+PIRD+", has been changed to "+PName
def deleteRecord(self):
if self.__fileOpen==True:
PIRD=self.__lstWorkers[self.__position].irdValue()
PName=self.__lstWorkers[self.__position].nameValue()
del self.__lstWorkers[self.__position]
if self.__position > len(self.__lstWorkers)-1:
self.__position = len(self.__lstWorkers)-1
strSQL="delete from workers where emplIRD = '"+PIRD+"'"
connection =sqlite3.connect("Workers.db")
cursor=connection.cursor()
cursor.execute(strSQL)
connection.commit()
cursor.close()
self.__fb = "Record for "+PIRD+", "+PName+" has been removed"
def __saveList(self):
self.__position = len(self.__lstWorkers)-1
currentObject= self.__lstWorkers[self.__position]
connection =sqlite3.connect("Workers.db")
cursor=connection.cursor()
strSQL="insert into workers values('"+currentObject.irdValue()+"', '" +currentObject.nameValue()+"', "+str(currentObject.hoursValue())+", "+str(currentObject.rateValue())
strSQL+=", "+str(currentObject.grossValue())+", "+str(currentObject.taxValue())+", "+str(currentObject.netValue())+")"
print(strSQL)
cursor.execute(strSQL)
connection.commit()
cursor.close()
def fileSize(self):
return(len(self.__lstWorkers))
def feedback(self):
return self.__fb
def currentRecord(self):
return self.__position
"""
The section below is procedural and contains the code for controllig the graphical
user interface
"""
def addRecord():
myWorker.newRecord(varIRD.get(),varName.get(),varHours.get(),varRate.get())
varFeedback.set(myWorker.feedback())
def modifyRecord():
myWorker.changeData(varIRD.get(),varName.get(),varHours.get(),varRate.get())
varFeedback.set(myWorker.feedback())
def deleteRecord():
myWorker.deleteRecord()
varFeedback.set(myWorker.feedback())
def firstRecord():
showData(myWorker.payFirst())
def lastRecord():
showData(myWorker.payLast())
def nextRecord():
showData(myWorker.payNext())
def previousRecord():
showData(myWorker.payPrevious())
def showData(currentObject):
varIRD.set(currentObject.irdValue())
varName.set(currentObject.nameValue())
varHours.set(currentObject.hoursValue())
varRate.set(currentObject.rateValue())
varGross.set(currentObject.grossValue())
varTax.set(currentObject.taxValue())
varNet.set(currentObject.netValue())
varFeedback.set("Record "+ str(myWorker.currentRecord()+1) +" of " + str(myWorker.fileSize()))
root = Tk()
frame1 = Frame(root, width = 420, height = 360)
frame1.pack()
varIRD=StringVar()
varName=StringVar()
varHours=DoubleVar()
varRate=DoubleVar()
varGross=DoubleVar()
varTax=DoubleVar()
varNet=DoubleVar()
varFeedback=StringVar()
irdLabel=tk.Label(master=frame1,text='IRD Number',width=15, anchor=E)
irdLabel.place(x = 60, y = 10)
nameLabel=tk.Label(master=frame1,text='Full Name',width=15, anchor=E)
nameLabel.place(x = 60, y = 45)
hoursLabel=tk.Label(master=frame1,text='Hours Worked',width=15, anchor=E)
hoursLabel.place(x = 60, y = 80)
rateLabel=tk.Label(master=frame1,text='Hourly Rate',width=15, anchor=E)
rateLabel.place(x = 60, y = 115)
grossLabel=tk.Label(master=frame1,text='Gross',width=15, anchor=E)
grossLabel.place(x = 60, y = 150)
taxLabel=tk.Label(master=frame1,text='Tax',width=15, anchor=E)
taxLabel.place(x = 60, y = 185)
netLabel=tk.Label(master=frame1,text='Net',width=15, anchor=E)
netLabel.place(x = 60, y = 220)
txtIRD=tk.Entry(master=frame1,relief=RAISED, textvariable=varIRD,width=15,bg="#ffffff", bd=1)
txtIRD.place(x = 180, y = 10)
txtName=tk.Entry(master=frame1,relief=RAISED, textvariable=varName,width=15,bg="#ffffff", bd=1)
txtName.place(x = 180, y = 45)
txtHours=tk.Entry(master=frame1,relief=RAISED, textvariable=varHours,width=15,bg="#ffffff", bd=1)
txtHours.place(x = 180, y = 80)
txtRate=tk.Entry(master=frame1,relief=RAISED, textvariable=varRate,width=15,bg="#ffffff", bd=1)
txtRate.place(x = 180, y = 115)
lblGross=tk.Label(master=frame1,relief=RAISED, textvariable=varGross,width=15,bg="#ffffff",bd=1)
lblGross.place(x = 180, y = 150)
lblTax=tk.Label(master=frame1,relief=RAISED, textvariable=varTax,width=15,bg="#ffffff", bd=1)
lblTax.place(x = 180, y = 185)
lblNet=tk.Label(master=frame1,relief=RAISED, textvariable=varNet,width=15,bg="#ffffff", bd=1)
lblNet.place(x = 180, y = 220)
addButton=tk.Button(master=frame1,text='Add', width=10, command=addRecord)
addButton.place(x = 80, y = 270)
modifyButton=tk.Button(master=frame1,text='Modify', width=10, command=modifyRecord)
modifyButton.place(x = 160, y = 270)
deleteButton=tk.Button(master=frame1,text='Delete', width=10, command=deleteRecord)
deleteButton.place(x = 240, y = 270)
firstButton=tk.Button(master=frame1,text='First', width=10, command=firstRecord)
firstButton.place(x = 40, y = 305)
lastButton=tk.Button(master=frame1,text='Last', width=10, command=lastRecord)
lastButton.place(x = 120, y = 305)
nextButton=tk.Button(master=frame1,text='Next', width=10, command=nextRecord)
nextButton.place(x = 200, y = 305)
previousButton=tk.Button(master=frame1,text='Previous',width=10,command=previousRecord)
previousButton.place(x = 280, y = 305)
feedbackLabel=tk.Label(master=frame1,textvariable=varFeedback,width=54)
feedbackLabel.place(x = 10, y = 340)
myWorker = dBase()
firstRecord()
root.title("Payroll")
root.mainloop()
